Home | C band LNB

C band LNB

Model No.: LCF-202

Product Name: C band twin LNB

1. Dual Polarity Switch
2. Digital Ready
3. Super low Noise
4. High Gain Output
5. Weather Proof
6. East Installation

1. Dual Polarity Switch
2. Digital Ready
3. Super low Noise
4. High Gain Output
5. Weather Proof
6. East Installation

Item	Specification	Item	Specification
Input Frequency Range	3.40～4.20GHz	L.O. Phase Noise	-70dBc/Hz@10KHz -90dBc/Hz@100KHz -110dBc/Hz@1MHz
Output Frequency Range	950-1750MHz	Image Rejection	40dB(Min.)
Noise Figure	15°K(Typ.)	Output VSWR	2.5:1(Max.)
Conversion Gain	65dB(Typ.)	Output Power	0dBm (Min.)(at 1dB gain compression)
Gain Flatness	±1dB(36MHz)	Connector Type	75Ω Female Connector
Cross POL. Isolator	20dB(Typ.)	DC Current Consumption	150mA (Max.)
L.O. Frequency	5.150GHz	F/D Ratio	0.28～0.42 (Adjustable)
L.O. Frequency Stability	±1.0MHz (Max.)@+25℃ ±2.0MHz (Max.)@-30℃～+70℃	Input Reflector Type	Prime focus
Operating Temperature	-30℃~+70℃	POL. Switching Voltage	10.5~14.0V@VP 16.0~20.0V@HP
