Model No.: MS-508C |
Product Name: Cascade Multiswitch 5x8 |
Features:
1.Design good for indoor usage.
2.4 satellite IF+1 Terrestrial input for 8 satellite receivers.
3.Built in Amplifiers.
4.Ideal for middle or large SMATV systems.
Specifications
|
Frequency |
Satellite: (MHz) |
950-2150 |
|
Terrestrial: (MHz) |
47-862 |
|
|
Inputs (F Connectors) |
4 Sat.+1 Terr.+ Power In |
|
|
Outputs (F Connectors) |
5 Trunk Out + 8 Taps |
|
|
Insertion Loss |
Trunk Sat. (dB) |
5 |
|
Trunk Terr. (dB) |
4 |
|
|
Tap Sat. (dB) |
2 |
|
|
Tap Terr. (dB) |
6 |
|
|
Isolator |
Trunk-Trunk (dB) |
30 |
|
Cross Polar (dB) |
28 |
|
|
Tap-Tap(Sat) (dB) |
30 |
|
|
Tap-Tap(Terr.) (dB) |
25 |
|
|
Rejection (dB) |
25 |
|
|
Return Loss |
Trunk in/out (dB) |
11 |
|
Tap (dB) |
8 |
|
|
Output Level |
Sat.(IMA335dB).EN50083-3 (dB) |
100 |
|
Terr.(IMA360dB) EN50083-5 (dB) |
90 |
|
|
Switching Voltage (V) |
18V |
|
|
LNB Power Supply Max. (A) |
1A |
|
|
Power Supply (Vac/Hz) |
External Power Adaptor110-240V/50/60Hz |
|
|
Switching Commands |
13V,18V,13V/22KHz,18V/22KHz, |
|
